Smart Net Claire SNC-A Series 1500VA to 3000VA
Product Features
- 2U space saving rackmount line-interactive UPS
- Pure sinewave UPS provides sensitive equipment with a consistent and clear output
- Voltage regulation is 1% as precise as in true online UPS
- Cost-effective UPS with complete power protection features, including HID enabled USB, RJ11/RJ45, EPO, RS232 and an optional SNMP card
- Provides economical power protection for IT equipment
| MODEL | SNC-A3000R |
|---|---|
| Capacity | 3000VA / 2100W |
| INPUT | |
| Nominal Voltage | 220 - 240VAC |
| Voltage Range | 165 - 290VAC |
| Frequency | 50 / 60Hz (Auto sensing) |
| Input Connections | BS 1363A Plug to IEC 320 C19 |
| OUTPUT | |
| Nominal Voltage (Battery Mode) | 220 - 240VAC |
| Frequency (Battery Mode) | 50Hz / 60Hz ± 1% |
| Total Harmonic Voltage Distortion (THDv) | ≤ 3% @ linear load, ≤ 5% @ non-linear load |
| Output connections | (3) BS 1363A |
| TOPOLOGY | |
| Transfer Time | 4ms (Typical) |
| Waveform (Battery Mode) | Pure sinewave |
| BATTERIES | |
| Battery Voltage | 24V |
| Battery Type | 12V 7AH |
| Typical Recharge Time | 4 hours recover to 90% capacity |
| Charging Current | 2A |
| SYSTEM | |
| LCD Display | Input Voltage, Output Voltage, Battery Percentage, Load Percentage and Faults |
| Audible Alarm | On Battery, Low Battery, Overload, Faults |
| SAFETY | |
| Overload Protection | On Utility: Circuit Breaker On Battery: Internal Firmwave Protection |
| RJ11 / RJ45 Surge Protection | Yes |
| Emergency Power Off (EPO) | Yes |
| COMMUNICATION / MANAGEMENT | |
| Auto Recharge | Yes |
| Auto Restart | Yes |
| USB Communication Port | HID Enabled |
| Intelligent Slot | SNMP (Optional) |
| Software | Windows 2000 / XP / 7 / 8 / 10 / Server 2003 / Vista / Server 2008 |
| STANDARDS / APPROVALS | |
| Compliances | CE, RoHS |
| IP Rating | IP 20 |
| ENVIRONMENT | |
| Operating Humidity | 0% - 90% (non-condensing) |
| Operating Temperature | 0℃- 40℃ |
| PHYSICAL PROPERTIES | |
| Dimensions ( W x D x H ) (mm) | 438 x 430 x 88 |
| Net weight (kg) | 21.78 |
| WARRANTY & SUPPORT | |
| Product Warranty | 3 Years Full Warranty For Parts and Labour. 2 Years For Batteries |
