Capacity (VA) |
2000VA / 1200W |
Phase |
Single Phase, 2 Wires + Earth |
INPUT |
Voltage Range |
162VAC - 280VAC |
Frequency Range |
50Hz or 60Hz (Auto Sense) |
Input Connections |
Fixed Power Cord with BS1363A Plug |
OUTPUT |
Output Voltage |
230VAC |
AC Voltage Regulation (Battery Mode) |
± 10% |
Frequency Range (Battery Mode) |
50 Hz or 60 Hz ± 1% |
Output Connections |
(4) BS 1363A |
TOPOLOGY |
Transfer Time (AC Mode to Battery Mode) |
Typical 2 - 6ms |
Waveform (Battery Mode) |
Simulated Sinewave |
BATTERIES |
Battery Capacity |
12V 9AH x 2 |
Autonomy |
Minimum 30 Minutes (Depending on the Equipment Loads) |
Typical Recharge Time |
4 - 6 Hours recover to 90% capacity |
SYSTEM |
Touch Panel |
Yes |
LCD Display |
Input Voltage, Output Voltage, Battery %, Load % and Fault |
Audible Alarm |
On Battery, Low Battery, Overload, Fault |
SAFETY |
RJ11 / RJ45 Surge Protection |
Yes |
Full Protection |
Overload, Discharge and Overcharge Protection |
COMMUNICATIONS / MANAGEMENT |
Auto Recharge |
Yes |
Auto Restart |
Yes |
USB Communication Port |
USB |
STANDARDS / APPROVALS |
Compliances |
CE |
IP Rating |
IP 20 |
ENVIRONMENT |
Operating Temperature |
0℃ - 45℃ |
Relative Humidity |
0% to 90% (non-condensing) |
Acoustic Level at 1m |
≤ 40dB |
PHYSICAL PROPERTIES |
Dimension (W x D x H) mm |
130 x 320 x 182 |
Net Weight (kg) |
11 |
WARRANTY & SUPPORT
|
Product Warranty |
3 Years Full Warranty For Parts and Labour. 2 Years For Batteries. |
